1000mm 48W LED City Color Wall Wash Light DC24V


Item No.: ST-WW-48W-AL-DMX. Private mould led wall washer with IP23, RGBW DMX, external driver.

Product details

LED wall washer is also called Outdoor LED Wall Washer, LED Wall washer light, led city color, led wall washer light ,etc. All of them with with Cree & Edison high power led. The led wall wash light Working Voltage: DC24V, AC110V or 220V, Constant current driver, No flash, fast response to achieve over-current,use of safty. RGB DMX512(1990 standard) and RDM system. No waterproof glue to seal the light, IP65 waterproof structure. Easy maintain and replace freely.

DMX decoder built inside, can be made with plug to plug connection.To make sure of high quality for the internal control LED Wall Washer Light, we use rubble cable.

Specifications of LED City Color Wall Wash Light.

Item Number ST-WW-48W-AL-DMX ST-WW-48W-AL-DMX
Input Voltage DC24V DC24V
Input Current 320--350mA 320--350mA
Driver place AC110-240V:External Driver AC110-240V:External Driver
Output Power 48W 48W
Luminous Flux Output 80LM/W 80LM/W
Rendering Index >70Ra(white color) >70Ra(white color)
Body size 45*62*1000MM 45*62*1000MM
Beam angle 10--90degree 10--90degree
Light source High power 1W LED High power 1W LED
Operating temperature -35 ∼ +45 Degrees Celsius -35 ∼ +45 Degrees Celsius
Storage temperature -35 ∼ +65 Degrees Celsius -35 ∼ +65 Degrees Celsius
Color optional RGBW, White(2700-6500K),R.Y.G.B RGBW, White(2700-6500K),R.Y.G.B
Housing material 6063 Aluminum 6063 Aluminum
LED's Operating Life ≥45,000Hours ≥45,000Hours
IP rate IP23 indoor use IP23 indoor use
Cable wire 1 meter female-male cable 1 meter female-male cable
RGB Control way Auto color change /DMX512 controllable Auto color change /DMX512 controllable
Features of LED City Color Wall Wash Light DC24V
  1. High quality die-casting Aluminum light body, be oxidized beauty and good heat dispersing performance. Private mold for all lamp housing.
  2. Sealing up the tempered glass with silicone gaskets to reach IP65 waterproof rate. No waterproof glue inside of lamp. You can replace PCB with led freely once problem happened.
  3. Using super-brightness and high power led chips. Built-in constant voltage power supply driver.
  4. PMMA optical lens. with beam angle 8 -90 degrees. Achieve different floor requests.
  5. Working voltage is: DC 24V,or AC110V-240V.
  6. Single color with steady-on; Auto-control color change synchronously. DMX512 controllable system.
  7. Long life, up to 45,000 hours.
Applications for 18W IP65 LED Wall Washer RGB DMX512 Control

Apply to Building, indoor or outdoor lights, Flooding for the landscape structure to outstanding building character. Hotels, airport, Metro. etc
